| Product Name |
Extreme Wireless WiNG AP7522 |
| 802.11AC Capabilities |
| Dual-band radios; supports 256-QAM 2X2 MIMO with 2 Spatial Streams |
| 20, 40, and 80 MHz Channels |
| 1.267 Gbps data rates on dual concurrent radio operations |
| Packet Aggregation (AMSDU, AMPDU) |
| Reduced Interface Spacing |
| 802.11 DFS |
| MIMO Power Save (Static and Dynamic) |
| Advanced forward error correction coding: STBC, LDPC |
| 802.11ac transmit beamforming |
| Maximal Ratio Combining (MRC) |
| Physical Characteristics |
| Dimensions |
7.1 in. L x 6.5 in. W x 1.6 in. H (180 mm L x 165 mm W x 41 mm H) |
| Weight |
1.8 lbs/0.82 kg |
| Housing |
Plenum-rated housing (UL2043) |
| Available Mounting |
No additional hardware required to mount |
| Configurations |
Above drop ceiling, under ceiling or on wall |
| LEDs Activity Indication |
2 top-mounted LEDs; activity indication |
| LAN Ethernet |
(1) x IEEE 802.3 Gigabit Ethernet auto-sensing |
| Antenna |
4dBi – 2.4 GHz band; 6 dBi – 5GHz band |
| Antenna Connectors |
(2) RP SMAs (External only — AP-7522-67040-xx) |
| Console Port |
RJ45 |
| User Environment |
| Operating Temperature |
– Internal antennas: 32° F to 104° F/ 0° C to 40° C |
| – External antennas: -4° F to 104° F/ -20° C to 40° C |
| Storage Temperature |
-40°F to 158°F / -40°C to 70°C |
| Operating Humidity |
85% RH non-condensing |
| Electrostatic Discharge |
– Internal AP-7522-67030-xx: 15kV air, 8kV contact |
| – External AP-7522-67040-xx: 12kV air, 6kV contact |
| Power Specifications |
| Operating Voltage |
48V |
| Operating Current |
280mA at 48V |
| Integrated PoE Support |
802.3af |
| Networking Specifications |
| Layer 2 and Layer 3 |
Layer 3 routing, 802.1q, DynDNS, DHCP server/client, BOOTP client, PPPoE and LLDP |
| Security |
Stateful Firewall, IP filtering, NAT, 802.1x, 802.11i, WPA2, WPA TripleMethodology Rogue Detection: 24×7 dual-band WIPS sensing, on-board IDS, and secure guest access (hotspot) |
| Quality of Service (QoS) |
WMM, WMM-UAPSD, 802.1p, Diffserv, and TOS |
| Radio Specifications |
| Wireless Medium |
Direct Sequence Spread Spectrum (DSSS), Orthogonal Frequency Division Multiplexing (OFDM), and Spatial Multiplexing (MIMO) |
| Network Standards |
EEE 802.11a/b/g/n/ac, 802.11d and 802.11i WPA2, WMM, and WMM-UAPSD |
| Data Rates Supported |
– 802.11b/g: 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 36, 48, and 54Mbps |
| – 802.11a: 6, 9, 12, 18, 24, 36, 48, and 54Mbps |
| – 802.11n: MCS 0-23 up to 300Mbps; Turbo mode (256QAM) on 2.4G band: up to 400Mbps |
| – 802.11ac: MCS 0-9 up to 866.7Mbps |
| Operating Channels and Frequencies |
– 2.4 GHz band: channel 1 through channel 13 |
| – 5.2 GHz band: channel 36 through channel 165 |
| – Channel availability depends on local regulatory restrictions |
| Antenna Configuration |
2×2 MIMO (transmit/receive on both antennas) |
| Transmit Power Adjustment |
1dB increment |
| Operating Frequencies |
2412 to 2472 MHz, 5180 to 5825 MHz |
| Certifications |
| Wi-Fi Alliance (WFA) certified 802.11a/b/g/n/ac |
| Accessories |
| Power Supply |
(37215) PWR 12VDC, 2A, 2.5mm x 5.5mm connector |
| PoE |
(PD-3501G-ENT) Single Port 802.3AF Midspan Device |
| Mounting |
– Mounting Plate for Indoor APs (37201) Include in box |
| – Universal Mounting Kit For Ewlan APS (KT-135628-01) |
| – BEAM CLIP for Mounting Plate (BRKT-000147A-01) |
| Maximum Conducted Transmit Power – One Antenna TX Power |
| Internal Antennas (AP-7522-67030-xx) |
– 2.4 GHz Band : 20 dBm |
| – 5 GHz Band : 20 dBm |
| External Antennas (AP-7522-67040-xx) |
– 2.4 GHz Band : 19 dBm |
| – 5 GHz Band : 18 dBm |
| Maximum Conducted Transmit Power – Two Antennas TX Power |
| Internal Antennas (AP-7522-67030-xx) |
– 2.4 GHz Band : 23 dBm |
| – 5 GHz Band : 23 dBm |
| External Antennas (AP-7522-67040-xx) |
– 2.4 GHz Band : 22 dBm |
| – 5 GHz Band : 21 dBm |
