Thông số kỹ thuật TerraMaster F2-221:
| Processor | |
| Processor Model | Intel® Celeron® J3355 |
| Processor Architecture | X.86 64-bit |
| Processor Frequency | Dual Core 2.0GHz (Max burst up to 2.5GHz) |
| Hardware Encryption Engine | Yes |
| Hardware Transcoding Engine | H.265 (HEVC), MPEG-4 Part 2, MPEG-2, VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 30 |
| Memory | |
| System Memory | 2GB |
| Total Memory Slot Number | 1 |
| Maximum Supported Memory | 6 GB (2GB+4GB) |
| Storage | |
| Disk Slot Number | 2 |
| Compatible Drive types | 3.5″ SATA HDD |
| 2.5″ SATA HDD | |
| 2.5″ SATA SSD | |
| Maximum Internal Raw Storage Capacity | 40TB (20TB x2) (Capacity may vary by RAID types) |
| Drive Hot Swap | Yes |
| File System | |
| Internal Drive | Btrfs, EXT4 |
| External Drive | EXT3, EXT4, NTFS, FAT32, HFS+ |
| External Ports | |
| RJ-45 1GbE Network Jack | 2 |
| USB3.0 Host Port | 2 |
| COM | 1 |
| HDMI | 1 |
| M.2 2280 NVMe Slot | 2 (PCIe3.0 x1) |
| Appearance | |
| Size (H*W*D) | 227 x 119 x 133 mm |
| Packaging Size (H*W*D) | 258 x 220 x 170 mm |
| Weight | 2.4 kg |
| Others | |
| System Fan | 80 x 80 x 25mm 1PCS |
| Fan Mode | Smart, High speed, Middle speed, Low speed |
| Noise Level | 26.4 dB(A) (Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in idle state) |
| Power Supply | 40 W |
| AC Input Voltage | 100V – 240V AC |
| Current Frequency | 50/60 Hz, Single frequency |
| Power Consumption | 22.1W(Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in read/write state) |
| 11.4 W (Fully loaded Seagate 4TB ST4000VN008 hard drive(s) in hibernation) | |
| Certificate | FCC, CE, CCC, KC |
| Environment | RoHS, WEEE |
| Temperature | |
| Working Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
| Storage Temperature | -20°C ~ 60°C (-5°F ~ 140°F) |
| Relative Humidity | 5% ~ 95% RH |
