Thông số kỹ thuật DAS TerraMaster D5-300:
|
Storage |
|
| Disk Slot Number | 5 |
| Compatible Disk Types | 3.5″ SATA HDD 2.5″ SATA HDD 2.5″ SATA SSD |
| File System | FAT 32, FAT 16, NTFS, and EXT4 |
| Maximum Internal Raw Capacity | 100TB (20 TB drive x 5) (Capacity will vary along with the RAID type) |
| RAIDs Supported | Support RAID 0, RAID 1, RAID 5, RAID 10, CLONE, JBOD, Single Disk |
| Hardware RAID | Yes |
| RAID Manager Software | Yes |
| RAID Manager Software Language | English, Chineses, Japanese, German, French, Spanish, Italian |
| External Ports | |
| USB | USB3.1 Type-C gen1 x 1 |
| Power Socket | DC IN 12V |
| Reading/writing Speed (max.) | |
| Reading Speed (max.) | Read：210MB/s (2 SSHD RAID0 mode) |
| Writing Speed (max.) | Write：190MB/s (2 SSHD RAID0 mode) |
| Appearance | |
| Size (H*W*D) | 227 x 225 x 136 mm |
| Packaging Size (H*W*D) | 300 x 275 x 186 mm |
| Weight | Net Weight: 2.1Kg Gross Weight: 3.5Kg |
| Others | |
| System fan | 80 mm x 80 mm x25mm (x 2) |
| Fan mode | Smart |
| Noise Level | 19.8dB(A) |
| Power Supply | |
| Power Supply | 90W |
| AC Input Voltage | 100V to 240V AC |
| Current Frequency | 50/60 HZ, Single Phase |
| Power Consumption | 45.6W(Access) |
| Environment Temperature | |
| Working Temperature | 5°C ~ 40°C (40°F ~ 104°F) |
| Storage Temperature | -20°C ~ 60°C (-5°F ~ 140°F) |
| Relative Humidity | 5% ~ 95% RH |
| Supported OS | Windows OS, Mac OS |
| Certificate | CE, FCC, CCC, KC |
| Environment | RoHS compliance |
