Đánh giá sản phẩm Router Switch MikroTIK CRS226-24G-2S+RM
The Cloud Router Switch CRS226-24G-2S+ is now available also in a 1U rackmount case, product code CRS226-24G-2S+RM. It is a fully functional Layer 3 switch powered by RouterOS. All the specific switch configuration options are available in a special switch menu. But if you want, ports can be removed from the switch configuration and used for routing purposes. It has 24 Gigabit ports and two SFP+ cages for 10G connectivity (first SFP port supports 1.25G/10G modules, second port only 10G modules)
Product specifications.
| Details | |
|---|---|
| Product code | CRS226-24G-2S+RM |
| SFP DDMI | Yes |
| CPU nominal frequency | 400 MHz |
| CPU core count | 1 |
| Architecture | MIPS-BE |
| Size of RAM | 64 MB |
| 10/100 Ethernet ports | None |
| 10/100/1000 Ethernet ports | 24 |
| MiniPCI slots | 0 |
| MiniPCI-e slots | 0 |
| Wireless chip model | None |
| Number of USB ports | 0 |
| Power Jack | 1 |
| PoE in | Yes |
| Voltage Monitor | Yes |
| PCB temperature monitor | Yes |
| CPU temperature monitor | No |
| Dimensions | 443x145x45mm |
| Operating System | RouterOS |
| Operating temperature range | -35C to +65C tested |
| License level | 5 |
| Current Monitor | No |
| CPU | QCA8519-AC2C |
| Max Power consumption | 21 W |
| SFP ports | None |
| SFP+ ports | 2 |
| Supported Voltage | 8-30V on Ether1 |
| Serial port | RJ45 |
