| CPU |
| CPU Model | AMD EPYC 7272 |
| CPU Quantity | 1 |
| CPU Architecture | 64-bit |
| CPU Frequency | 12-core 2.9 (base) / 3.2 (turbo) GHz |
| Hardware Encryption Engine (AES-NI) | Yes |
| Memory |
| System Memory | 32 GB DDR4 ECC RDIMM |
| Memory Module Pre-installed | 32 GB (32 GB x 1) |
| Total Memory Slots | 16 |
| Maximum Memory Capacity | 1024 GB (64 GB x 16) |
| Storage |
| Drive Bays | 12 |
| Maximum Drive Bays with Expansion Unit | 108 (RX1223RP x 8) |
| Compatible Drive Type* (See all supported drives) | 3.5″ SATA HDD |
| 2.5″ SATA SSD |
| Hot Swappable Drive* | Yes |
| External Ports |
| RJ-45 1GbE LAN Port | 4 (with Link Aggregation / Failover support) |
| RJ-45 10GbE LAN Port | 2 (with Link Aggregation / Failover support) |
| Management LAN Port | 1 |
| Max. number of LAN ports | 15 |
| USB 3.2 Gen 1 Port* | 2 |
| Expansion Port | 8 |
| PCIe |
| PCIe Expansion | 2 x Gen3 x8 slots (x8 link) |
| Appearance |
| Form Factor (RU) | 2U |
| Size (Height x Width x Depth) | 88 mm x 482 mm x 724 mm |
| Weight | 16.5 kg |
| Rack Installation Support* | 4-post 19″ rack (Synology Rail Kit – RKS-02) |
| Notes | The rail kit is sold separately |
| Others |
| System Fan | 80 mm x 80 mm x 4 pcs |
| Noise Level* | 55.5 dB(A) |
| Power Supply Unit / Adapter | 550 W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | 180.5 W (Access) |
| 88.56 W (HDD Hibernation) |
| British Thermal Unit | 615.89 BTU/hr (Access) |
| 302.18 BTU/hr (HDD Hibernation) |
| Temperature |
| Operating Temperature | 0°C to 35°C (32°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
