Aggregation 10G Switch MES5324
MES5324 aggregation Ethernet switches: 1×10/100/1000BASE-T (ООВ), 1х10/100/1000BASE-T (Management in-band), 24x10GBASE-R(SFP+)/1000BASE-X (SFP), 4x40GBASE-SR4/LR4 (QSFP)
Bandwidth 800 Gbps
Non-blocking architecture
24x10G ports, 4x40G ports
L3 switch
Front-to-back cooling
Stacking up to 8 devices
Hot-swappable redundant power supplies
Hot-swappable fans
Eltex MES5324 switches are high performance devices with 10GBASE-R and 40GBASE-SR4/LR4 interfaces that can be used as aggregation or transport switches in carrier networks and as Top-of-Rack or End-of-Row switches for data centers.
The non-blocking architecture guarantees lossless packet forwarding at wire speed with minimum and predictable delays for all types of traffic. The front-to-back cooling provides effective cooldown in modern data centers.
The redundant and hot-swappable fans and AC/DC power supplies with advanced hardware monitoring functions provide high reliability and uninterrupted services.
Parameters
Packet processor Marvell98CX8129
Interfaces:
– 1×10/100/1000Base-T (ООВ)
– 1х10/100/1000Base-T (Management in-band)
– 24x(10G Base-X(SFP+)/1000Base-X (SFP)
– 4x40G Base-SR4/LR4 (QSFP)
Console port RS-232/RJ-45
Bandwidth 800 Gbps
Buffer memory 32 Mbit
MAC table 64K
VLAN table 4K
L2 Multicast groups 4К
ARP table¹ 8К
Link Aggregation Groups (LAG): 16, up to 8 ports per LAG
Quality of Service (QoS): 8 egress queues per port
TCAM: for routing: 8192; for traffic processing: 8192х24 В
Jumbo frames size: 10240 bytes
Stacking: 8 devices
Physical parameters
Power: 220V +-20%, direct current network -36..-72V
Power supply: one power source of direct or alternative current or two power sources of direct or alternative current with hot change
Max power consumption 85W
Front-to-back ventilation, 4 fans
Operating temperature from -5°C..+50°C
Operating humidity 80% max
Storage temperature -40°C..+70°C
Dimensions 430x298x44 mm
Weight 3.95 kg
